Milwaukee K 950 S 10 Kg Class Drilling And Breaking Hammer 4933375685
SKU: SKU250626193453002
EAN: 4002395232031
Milwaukee
Price Comparison
No recent prices available for this product
Prices are updated regularly. Please check back later.Product Description
| Condition | |
|---|---|
| New: A genuine product, unused and unopened in original packaging. |
| Main Product Information | |
|---|---|
| Brand | Milwaukee |
| Model | K 950 |
| MPN | 4933375685 |
| EAN | 4002395232031 |
| Product Category | Power Tools | Drilling and Chipping | SDS Max |
| Description | |
|---|---|
| Specifications | |
|---|---|
| Blow energy (EPTA)(J) | 20 |
| Full load hammer action (bpm) | 975 - 1950 |
| Full load speed (soft hammer) (rpm) | 125 - 250 |
| Max. drilling core bit (mm) | 150 |
| Max. drilling solid bit (mm) | 50 |
| Max. drilling tunnel bit (mm) | 80 |
| No load speed (rpm) | 125 - 250 |
| Power input (W) | 1700 |
| Standard equipment | Additional front spade handle, auxiliary straight handle, dust shield, grease |
| Supplied in | Kitbox |
| Tool reception | SDS-Max |
| Article Number USA | 4933375685 |
| Article Number EU 220-240V | 4933375710 |
| Article Number IT | 4933405365 |
| EAN | 4002395232031 |
| Weight (kg) | 11.8 |
| Sound power level (Lwa)(dB(A)) | 11 |
| Sound power level uncertainty (dB(A)) | 3 |
| Sound pressure level (Lpa)(dB(A)) | 100 |
| Sound pressure level uncertainty (dB(A)) | 3 |
| Vibration chiseling (m/s²) | 11 |
| Vibration chiselling uncertainty (m/s²) | 2 |
| Vibration drilling (m/s²) | 12.5 |
| Vibration drilling into concrete [m|s²] | 11 |
| Vibration drilling into concrete uncertainty [m|s²] | 2 |
| What's Included | |
|---|---|
|
| Spare Parts | ||
|---|---|---|
 | ||
| Part Code | Description | Quantity |
|---|---|---|
| 4931256500 | CABLE COLLAR | 1 |
| 4931317212 | RUBBER SLEEVE | 1 |
| 4931339996 | SCREW | 2 |
| 4931341741 | BALL BEARING | 1 |
| 4931374974 | DAMPING ELEMENT | 1 |
| 4931375378 | SPINDLE | 1 |
| 4931375380 | PISTON COMPL. | 1 |
| 4931375401 | LOCKING PLATE | 1 |
| 4931375412 | BACK-PRESSURE RING | 1 |
| 4931375416 | ATTACHMENT RING | 1 |
| 4931375418 | WASHER | 1 |
| 4931375419 | BALL RACE | 1 |
| 4931375420 | THRUST COLLAR | 1 |
| 4931375423 | DRIVER | 1 |
| 4931375443 | GEAR COVER | 1 |
| 4931375458 | SWITCH | 1 |
| 4931375474 | FAN | 1 |
| 4931375477 | THRUST PIECE | 1 |
| 4931375488 | BEARING END PLATE | 1 |
| 4931375489 | SEAL RING | 1 |
| 4931375506 | GASKET | 1 |
| 4931375508 | FELT | 1 |
| 4931375515 | AIR DEFLECTOR RING | 1 |
| 4931375529 | PRESSURE SPRING | 1 |
| 4931375530 | TRANSITION PIECE | 1 |
| 4931375531 | SECURED WASHER | 1 |
| 4931375535 | SERVICING LID | 1 |
| 4931375546 | LEVER | 1 |
| 4931375556 | CARBON BRUSH SET | 1 |
| 4931375560 | PAIR HANDLE SHELLS | 1 |
| 4931375569 | SEAL RETAINER | 1 |
| 4931375573 | SNAP DIE | 1 |
| 4931375583 | ADJUSTING PLATE | 1 |
| 4931375594 | PRESSURE SPRING | 1 |
| 4931375595 | DISC | 1 |
| 4931375669 | ELECTRIC FIELD | 1 |
| 4931375740 | MOTOR HOUSING | 1 |
| 4931375762 | CARRYING CASE | 1 |
| 4931375769 | INTERLOCK ELEMENT | 2 |
| 4931375770 | INTERLOCK PLATE | 1 |
| 4931375774 | INTERLOCK SLEAVE | 1 |
| 4931375775 | DAMPING RING | 1 |
| 4931375776 | SPINDLE SLEEVE | 1 |
| 4931375782 | PERCUSSION BODY | 1 |
| 4931375787 | DRIVER | 4 |
| 4931375791 | MAINTENANCE SET | 1 |
| 4931375828 | HANDLE | 1 |
| 4931375836 | ARMATURE | 1 |
| 4931381694 | BRUSH HOLDER | 2 |
| 4931392174 | PROTECTING COVER | 1 |
| 4931396199 | SET COLLAR | 1 |
| 4931398189 | GROOVED BALL BEAR. | 1 |
| 4931409106 | ELECTRONIC | 1 |
| 4931409549 | THRUST BEARING | 1 |
| 4931409625 | BACK-PRESSURE RING | 1 |
| 4931409626 | ATTACHMENT RING | 1 |
| 4931412446 | GEAR BOX | 1 |
| 4931412447 | GEAR BOX COVER | 1 |
| 4931417686 | MODIFICATION SET | 1 |
| 4931417697 | REPAIR KIT | 1 |
| 4931603515 | SEALING WASHER | 6 |
| 4931621847 | NEEDLE BEARING | 2 |
| 4931622166 | O-RING N874701 26X3 | 1 |
| 4931622765 | SCREW N874101-1 SHR C-K5X45/20 KOMBITORX | 5 |
| 4931624153 | SPRING RING N874268 SW 20 | 1 |
| 4931624155 | SEAL RING N874701 28X5 | 3 |
| 4931624156 | SEAL RING N874701 28X5 | 2 |
| 4931624157 | SEAL RING N874701 28X5 | 2 |
| 4931624158 | SEAL RING N874701 28X5 | 2 |
| 4931624161 | SEAL RING N874701 28X5 | 1 |
| 4931624170 | SEAL RING | 4 |
| 4931624205 | SEAL RING | 1 |
| 4931624213 | SCREW | 4 |
| 4931624234 | SCREW | 8 |
| 4931624235 | RETAINING RING | 1 |
| 4931624237 | SEAL RING | 1 |
| 4931624263 | WIRE | 2 |
| 4931624276 | SCREW D 912 M5X16 8.8SSI | 9 |
| 4931624362 | CONNECTION CABLE | 1 |
| 4931624537 | SCREW | 2 |
| 4931624538 | SCREW | 4 |
| 4931624658 | SCREW | 2 |
| 4931890311 | LOCKING RING | 1 |
| 9170316570 | Chuck Cover | 1 |
| 9170319040 | SPRING RING | 1 |
| 9170350243 | END COVER CAP | 1 |
Specifications
| Brand | Milwaukee |
| Closed Length | TBA |
| Colour | Red |
| Country/Region of Manufacture | TBA |
| Handle Material | TBA |
| Handle Size | TBA |
| Head/Face Material | TBA |
| Item Diameter | TBA |
| Item Height | TBA |
| Item Length | TBA |
| Item Weight | TBA |
| Item Width | TBA |
| Manufacturer Warranty | TBA |
| Model | K 950 |
| MPN | 4933375685 |
| Number of Pieces | TBA |
| Personalisation Instructions | TBA |
| Personalise | TBA |
| Type | SDS Max |
| Unit Quantity | 1 |
| Unit Type | Unit |
Manufacturer Information
About
Milwaukee Tool is a heavy-duty power tool, hand tool and accessories manufacturer focused on professional trades, known for cordless innovation and jobsite solutions.
UK Contact
Techtronic Industries (UK) Limited, Suite A, Second Floor, Parkway, Marlow, Bucks, SL7 1YL, England
Product Range
Cordless and corded power tools, hand tools, measuring/instrumentation, accessories (blades, bits, fixings), storage systems (e.g., modular storage), and PPE for professional users.
